System Specifications
Standard
- IEEE 802.3 10BASE-T Ethernet
- IEEE 802.3u 100BASE-TX Fast Ethernet
- IEEE 802.3ab 1000BASE-T Gigabit Ethernet
- IEEE 802.3 Nway auto-negotiation
- IEEE 802.3x full duplex operation and flow control
- IEEE 802.3az Energy Efficient Ethernet
Performance
- Data transfer rate (half duplex/full duplex): Ethernet: 10/20 Mbps, Fast Ethernet: 100/200 Mbps, Gigabit Ethernet: 1000/2000 Mbps
- MAC address table: 4 K
- Memory buffer: 128 KB
- Switching fabric (non-blocking): 16 Gbps
Features
- Auto-MDI/MDIX in all ports
- Transmission method: Store-and-forward architecture
- Port-based QoS support
- Jumbo frame support up to 9 KB
Hardware Specifications
- Interface Eight RJ-45 10/100/1000 Mbps Ethernet ports with auto MDI/MDIX support
- QoS Ports Two high-priority QoS ports and two medium-priority QoS ports
- LED Indicator: PWR: Power, Per port: Link/Activity Amber: 10/100 Mbps, Green: 1000 Mbps
- Power Supply Input: 100-240 V AC, Output: 5 V DC, 1 A
- Power consumption: 3.0 watt max.
Physical Specifications
- Item dimensions (WxDxH): 155 x 85 x 26 mm (6.1″ x 3.3″ x 1.0″)
- Item weight: 325 g
-
Certification: CE, FCC Class B, BSMI
Environmental Specifications
- Operating Environment: Temperature: 0 C to 40 C (32 F to 104 F), Humidity: 10% to 90% (Non-condensing)
- Storage Environment: Temperature: -40 C to 70 C (-40 F to 158 F), Humidity: 10% to 95% (Non-condensing)
