ZyXEL ZXL-VES-1724-56 Warranty 2 Year

System Specifications

• 16K MAC addresses
• 256 static MAC address filtering
• Port security
• Broadcast/Multicast/Destination Lookup fail storm control
• Spanning Tree Protocol (IEEE 802.1D)
• QoS (IEEE 802.1P, 8 priority queues)
• Port-based and tag-based (IEEE 802.1Q) VLAN
• GVRP for automatic VLAN membership registration
• Link Aggregation (IEEE 802.3ad)
• IGMP snooping
• MVR
• RMON
• SNMP
• MIB II, RFC1493, 2674 and 1757 MIB, and private MIB
• Web management
• FTP for firmware upgrade
• CLI through Console port and telnet
• IPv6
• VDSL2 bonding*
• ADSL2+ fallback & bonding*
• G.INP (G.998.4)

Hardware Specifications

• 1.5U
• 19” rack mountable
• Front access:
  •  One Telco 50 for 24 VDSL ports
  •  One Telco 50 for 24 POST ports
  •  2-slot 100/1000 Mbps Ethernet uplink/downlink
  •  2-slot Gigabit fiber uplink/downlink (Combo)
  •  Built-in POTS splitter supports 600 ohm ETSI
• AC and DC dual power (Power Redundancy)
  •  AC input: 100V AC to 264V AC, 60 Hz ± 3 Hz
  •  DC input: -36V DC to -72V DC

Physical Specifications

• Item dimensions (WxDxH): 440 x 300 x 66 mm (17.32” x 11.81” x 2.6”)
• Item weight: 5,000 g (11.05 lb.)
• Packing dimensions (WxDxH): 560 x 523 x 675 mm (22.04” x 20.59” x 26.57”)
• Packing weight: 6,700 g (14.81 lb.)

Environmental Specifications

Operating Environment

• Temperature: 0°C to 65°C (32°F to 149°F)
• Humidity: 10% to 95% (Non-condensing)

Storage Environment

• Temperature: -40°C to 70°C (-40°F to 158°F)
• Humidity: 5% to 95% (Non-condensing)

Certification

• RoHS
• K.20
• ETSI300-019
• Safety
  •  EN60950-1
  •  CSA60950-1
  •  UL60950-1
  •  IEC60950-1
• EMC
  •  FCC Part 15 Class A
  •  EN55022 Class A
  •  ETSI300-386
