Standard
- IEEE 802.3 10BASE-T Ethernet
- IEEE 802.3u 100BASE-TX Fast Ethernet
- IEEE 802.3ab 1000BASE-T Gigabit Ethernet
- IEEE 802.3 Nway auto-negotiation
- IEEE 802.3x full duplex operation and flow control
- IEEE 802.3az Energy Efficient Ethernet
Performance
- Data transfer rate (half duplex/full duplex):
- Ethernet: 10/20 Mbps
- Fast Ethernet: 100/200 Mbps
- Gigabit Ethernet: 1000/2000 Mbps
- MAC address table: 2K
- Memory buffer: 128 KB
- Switching fabric (non-blocking): 10 Gbps
Features
- Auto-MDI/MDIX in all ports
- Transmission method:
- Store-and-forward architecture
- Port-based Quality of Service (QoS) support
- Jumbo Frame support up to 9 KB
Interface
- Five RJ-45 10/100/1000 Mbps Ethernet ports with auto MDI/MDIX support
QoS Ports
- One high-priority QoS port, two medium-priority QoS ports, and two low-priority QoS ports
LED Indicator
- PWR: Power
- Per port: Link/Activity
- Amber: 10/100 Mbps
- Green: 1000 Mbps
Power supply
- Input: 100V-240V AC
- Output: 5V DC, 1A
Power Consumption
- 2.5 watt max.
- Item dimensions (WxDxH): 99.1 x 67.6 x 28.6 mm (3.9″ x 2.7″ x 1.1″)
- Item weight: 79g (0.17 lb.)
- Packing dimensions (WxDxH): 103 x 82 x 92 mm (4.1″ x 3.2″ x 3.6″)
- Packing weight: 221g (0.49 lb.)
