Mode
O3
Dimension
270*94.86*67.5mm
Deployment
Pole Mount
Application Scenarios
WISP CPE, Data transmission and Long range video surveillance
Frequency
2.4GHz
Maximum wireless speed
150Mbps
Interface
2*10/100Mbps Ethernet Port
Antenna
12dbi
Antenna Beamwidth
Horizontal: 60°
Elevation: 30°
Elevation: 30°
Reset Button
1
GND Terminal
1
Power Consumption
4.3W
Waterproof Level
IP64
LED indicator
PoE/LAN,LED1,LED2,LED3
Power Method
12V1A Passive PoE
Lightning Protection
6000V
Passive PoE power supply
Passive power over ethenet via PoE/LAN ( 4,5pins -7,8pins)
Voltage range: 11-13.8V DC
Voltage range: 11-13.8V DC
Reception Sensitivity
MCS0: -96dbm
MCS7: -72dbm
MCS7: -72dbm
Operating mode
AP/Station/WISP/P2MP/WDS Repeater/Router
Standard&Protocol
IEEE 802.11b/g/n
Enable/Disable Wireless Radio
Support
SSID Hidden
Support
Wireless Client isolation
Support
SSID Isolation
Support
Client Limitation For SSID
Support
Wireless Access Control
Support
Weak Signal Client Limitation
Support
Transmit Power
Adjustable power by 1dBm
WMM Capable
Support
APSD Capable
Support
Wireless Security
64/128 WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK,WPA,WPA2
Transmission Media
Support
VLAN Tagging for SSID
Support
DHCP Server
Support
VPN Pass-through
PPTP,L2TP
Remote Web access
Support
Schedule Reboot
Support
Page Timeout
Support
Ping Watchdog
Support
Dyndns
noip, dyndns.org
Network Diagnoses
Ping, Traceroute, Signal Scan
Time&Date Setting
Support
Firmware Upgrade
Support
Backup/Restore Configuration
Support
Username Managerment
Support
Syslog
Support
Managed By Controller
PC Software — CPE Assistant
Package Content
1*5km Point to Point Outdoor CPE
1*Power Adapter
1*PoE Injector
2*Plastic Staps
1*Quick Installation Guide
1*Power Adapter
1*PoE Injector
2*Plastic Staps
1*Quick Installation Guide
Temperature
Operating Temperature:-30℃ ~ 60℃
Storage Temperature:-40℃ ~ 70℃
Storage Temperature:-40℃ ~ 70℃
Humidity
Operating Humidity:10%~90% non-condensing
Storage Humidity:10%~90% non-condensing
Storage Humidity:10%~90% non-condensing
Default Settings
Default login IP:192.168.2.1
Default Login Username:admin
Default Login Password:admin
Default Login Username:admin
Default Login Password:admin
Certification
FCC/CE/RoHS
