DS218j

Synology DiskStation DS218j 2-bay NAS Warranty 2 years

2-bay DiskStation, Dual Core 1.3 GHz, 512MB RAM
Warranty 2 years

หมวดหมู่: Network & Disk Station, Storage & NAS, SYNOLOGY

รายละเอียด
บทวิจารณ์ (0)

Hardware Specifications
CPU
CPU Model	Marvell Armada 385 88F6820
CPU Architecture	32-bit
CPU Frequency	Dual Core 1.3 GHz
Hardware Encryption Engine
Memory
System Memory	512 MB DDR3
Notes	Synology reserves the right to replace memory modules with the same or higher frequency based on supplier’s product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Storage
Drive Bays	2
Compatible Drive Type* (See all supported drives)	3.5″ SATA HDD 2.5″ SATA HDD (with optional 2.5″ Disk Holder) 2.5″ SATA SSD (with optional 2.5″ Disk Holder)
Maximum Internal Raw Capacity	28 TB (14 TB drive x 2) (Capacity may vary by RAID types)
Maximum Single Volume Size	16 TB
Hot Swappable Drive
Notes	“Compatible drive type” indicates the drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay. The maximum raw capacity is not limited by the maximum single volume size. Synology NAS models may utilize capacities over the maximum single volume size as long as each volume created is below the limit. (Learn more)
External Ports
RJ-45 1GbE LAN Port	1
USB 3.0 Port	2
File System
Internal Drives	EXT4
External Drives	EXT4 EXT3 FAT NTFS HFS+* exFAT*
Notes	HFS+ is read only, max 2TB volume size. exFAT Access is purchased separately in Package Center.
Appearance
Size (Height x Width x Depth)	165 mm x 100 mm x 225.5 mm
Weight	0.88 kg
Notes	The rail kit is sold separatelty.
Others
System Fan	92 mm x 92 mm x 1 pcs
Fan Speed Mode	Full-Speed Mode Cool Mode Quiet Mode Low-power Mode
Brightness adjustable front LED indicators
Power Recovery
Noise Level*	18.2 dB(A)
Scheduled Power On/Off
Wake on LAN/WAN
Power Supply Unit / Adapter	60W
AC Input Power Voltage	100V to 240V AC
Power Frequency	50/60 Hz, Single Phase
Power Consumption*	17.48 W (Access) 7.03 W (HDD Hibernation)
British Thermal Unit	59.68 BTU/hr (Access) 24 BTU/hr (HDD Hibernation)
Environment Temperature
Operating Temperature	5°C to 40°C (40°F to 104°F)
Storage Temperature	-20°C to 60°C (-5°F to 140°F)
Relative Humidity	5% to 95% RH
Certification	EAC CCC RCM KC FCC CE BSMI
Warranty	2 Years
Notes	Power consumption is measured when fully loaded with Western Digital 1TB WD10EFRX hard drive(s). Noise Level Testing Environment: Fully loaded with Seagate 2TB ST2000VN000 hard drive(s) in idle; Two G.R.A.S. Type 40AE microphones, each set up at 1 meter away from the Synology NAS front and rear; Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
DSM Specifications ( See more )
Storage Management
Maximum Internal Volume Number	256
Maximum iSCSI Target Number	10
Maximum iSCSI LUN	10
Supported RAID Type	Synology Hybrid RAID Basic JBOD RAID 0 RAID 1
RAID Migration	Basic to RAID 1
Volume Expansion with Larger HDDs	Synology Hybrid RAID RAID 1
Volume Expansion by Adding a HDD	Synology Hybrid RAID
File Services
File Protocol	CIFS/AFP/NFS/FTP/WebDAV
Maximum Concurrent CIFS/AFP/FTP Connections	100
Windows Access Control List (ACL) Integration
NFS Kerberos Authentication
Account & Shared Folder
Maximum Local User Accounts	1024
Maximum Local Groups	256
Maximum Shared Folder	256
Maximum Shared Folder Sync Tasks	2
Log Center
Syslog Events per Second	100
Add-on Packages (learn more about the complete add-on package list)
Chat
Maximum Users	10
Notes	The number of concurrent HTTP connections for Chat was configured to the maximum. CPU and RAM usage were both under 80% when the number of maximum users was reached.
Cloud Station Server
Maximum Number of Concurrently Connected Devices	100
Maximum Number of Hosted Files (ext4)	100,000
Notes	The maximum number of concurrently connected devices refers to the maximum number of devices that can remain connected at the same time. The maximum number of hosted files refers to the maximum number of files that can be indexed and hosted by the Cloud Station Server service. RAM expansion was not used during testing. Non-encrypted shared folders were used during the aforementioned testing.
Download Station
Maximum Concurrent Download Tasks	30
exFAT Access (optional)
Media Server
DLNA Compliance
Moments
Facial recognition
Subject recognition
Auto Color & Rotate
Moments Select
Surveillance Station
Maximum IP cam (Licenses required)	14 (including 2 Free License) (See All Supported IP Cameras)
Total FPS (H.264)*	420 FPS @ 720p (1280×720) 120 FPS @ 1080p (1920×1080) 90 FPS @ 3M (2048×1536) 60 FPS @ 5M (2591×1944) 20 FPS @ 4K (3840×2160)
Total FPS (H.265)*	420 FPS @ 720p (1280×720) 210 FPS @ 1080p (1920×1080) 140 FPS @ 3M (2048×1536) 90 FPS @ 5M (2591×1944) 30 FPS @ 4K (3840×2160)
Total FPS (MJPEG)*	140 FPS @ 720p (1280×720) 70 FPS @ 1080p (1920×1080) 40 FPS @ 3M (2048×1536) 20 FPS @ 5M (2591×1944)
Notes	Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera.
Synology Drive
Recommended Number of Hosted Files	100,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)
Recommended Number of Concurrent Connections for PC Clients	200 (the number of connections that can be maintained when the recommended number of hosted files was reached)
Notes	Exceeding the limits above may result in longer response time in file operations. EXT4 file system and non-encrypted shared folders were used during the aforementioned testing.
Synology Office
Maximum Users	200
Notes	Multiple files were opened for testing and each file was edited by 30 users simultaneously. CPU and RAM usage were both under 80% when the number of maximum users was reached. Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM
Video Station
Video Transcoding	Group 2 (See more)
VPN Server
Maximum Connections	10
Environment & Packaging
Environment	RoHS Compliant
Packaging Content	Main Unit X 1 Accessory Pack X 1 AC Power Adapter X 1 AC Power Cord X 1 RJ-45 LAN Cable X 1 Quick Installation Guide X 1
Optional Accessories	Surveillance Device License Pack Disk Holder: Type C VS360HD VS960HD
