Camera
Image Sensor: 1MP CMOS Image Sensor
Signal System: PAL/NTSC
Effective Pixels: 1296(H)x732(V)
Min. Illumination: 0.1 Lux@(F1.2, AGC ON), 0 Lux with IR
Shutter Time: 1/25(1/30) s to 1/50,000 s
Lens: 2.8 mm, 3.6 mm, 6 mm
Lens Mount: M12
Adjustment Range: Pan: 0°to 360°, Tilt: 0°to 180°, Rotation: 0°to 360°
Day& Night: IR cut filter with auto switch
Video Frame Rate: 720p@25fps/720p@30fps
HD Video Output: 1 Analog HD output
Synchronization: Internal Synchronization
S/N Ratio: More than 62 dB
General
Operating Conditions: -40 °C – 60 °C (-40 °F – 140 °F)
Humidity 90% or less (non-condensing)
Power Supply: 12 VDC±15%
Power Consumption: Max. 4 W
Weather Proof: IP66
IR Range: Up to 40m
Dimension: Ø 110 mm × 94.52 mm (Ø 4.33″ × 4.35″)
Weight: 240 g (0.53 lb.)
