Camera
WDR (Wide Dynamic Range): > 120 dB
Image Sensor: 2MP CMOS Image Sensor
Signal System: PAL/NTSC
Effective Pixels: 1920(H)*1080(V)
Min. Illumination: Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Time: 1/25(1/30) s to 1/50,000 s
Lens: 2.8 mm, 3.6 mm, 6 mm fixed lens
Lens Mount: M12
Adjustment Range: Pan: 0°to 360°, Tilt: 0°to 180°, Rotation: 0°to 360
Day& Night: IR cut filter with auto switch
Video Frame Rate: 1080p@25fps/1080p@30fps
HD Video Output: 1 Analog HD output
Synchronization: Internal Synchronization
Lens
Horizontal Field of View: 106° (2.8 mm), 82° (3.6 mm), 51° (6 mm)
Menu
D/N Mode: Auto/Color/BW (Black and White)
BLC: Support
AGC: High/Medium/Low/Off
Language: English
Function: Brightness, Sharpness, DNR, Mirror, Smart IR
General
Material: Metal
Operating Conditions: -40 °C – 60 °C (-40 °F – 140 °F)
Humidity 90% or less (non-condensing)
Power Supply: 12 VDC±25%
Power Consumption: Max. 5.6 W
Weather Proof: IP66
IR Range: Up to 50m
Dimension: 75.4mm × 230.8 mm × 87.2 mm (2.97″ ×9.09″ × 3.43″)
Weight: 352 g (0.78 lb.)
