- Camera
- Image Sensor1/2.8″ Progressive Scan CMOS
- Min. IlluminationColor: 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR
- Shutter Speed1/3 s to 1/100,000 s
- Slow ShutterYes
- Day &NightIR cut filter
- Wide Dynamic RangeDigital WDR
- Angle AdjustmentPan: 0° to 360°, tilt: 0° to 75°, rotation: 0° to 360°
- Lens
- LensFixed lens, 2.8/4 mm
- ApertureF2.0
- FOV2.8mm: Horizontal FOV: 114°, vertical FOV: 62°, diagonal FOV: 135° 4 mm: Horizontal FOV: 86°, vertical FOV: 46°, diagonal FOV: 102°
- Lens MountM12
- Illuminator
- IR RangeUp to 30 m
- Wavelength850 nm
- Network
- ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP
- APIONVIF (PROFILE S, PROFILE G), ISAPI
- Simultaneous Live ViewUp to 6 channels
- User/HostUp to 32 users,3 levels: Administrator, Operator and User
- ClientHiLookVision PC Client, HiLookVision App
- Web BrowserIE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11
- Video
- Max. Resolution1920 × 1080
- Main Stream50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
- Sub Stream50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
- Video CompressionMain stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG
- H.264 TypeBaseline Profile/Main Profile/High Profile
- H.265 TypeMain Profile
- Video Bit Rate32 Kbps to 8 Mbps
- Audio
- Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM
- Audio Bit Rate64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
- Smart Feature-Set
- Basic EventMotion detection, video tampering alarm, exception (illegal login)
- Region of Interest1 fixed region for main stream and sub-stream
- Image
- Image EnhancementBLC, 3D DNR
- Image SettingRotate mode, saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser
- Day/Night SwitchDay/Night/Auto/Schedule
- Interface
- Communication Interface1 RJ45 self-adaptive Ethernet port
- Audio1 audio input (built-in microphone), mono sound
- Interface StylePigtail style interface
- General
- Firmware Version5.5.83
- General FunctionOne-key reset, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
- ResetReset via web browser and client software
- Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
- Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing)
- Power Supply12 VDC ± 25%, Φ 5.5 mm coaxial power plug; PoE (802.3af, class 0)
- Power Consumption and Current12 VDC, 0.4 A, max. 5 W; PoE (802.3af, 36 V to 57 V), 0.20 A to 0.10 A, max. 6.5 W
- MaterialCamera body: metal, bottom base : plastic
- DimensionsCamera: 95 × Φ110 mm (3.7″ × Φ4.3″) With package: 150 × 150 × 141 mm (5.9″ × 5.9″ × 5.6″)
- Camera: Approx. 355 g (0.78 lb.) With package: Approx. 684 g (1.5 lb.)
- Approval
- EMC47 CFR Part 15, Subpart B; EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014; AS/NZS CISPR 32: 2015; ICES-003: Issue 6, 2016; KN 32: 2015, KN 35: 2015
- SafetyUL 60950-1, IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC/EN 60950-1
- Chemistry2011/65/EU, 2012/19/EU, Regulation (EC) No 1907/2006
- ProtectionIngress protection: IP66 (IEC 60529-2013)
