- Recording
- Encoding resolution1080p lite/720p/VGA/WD1/4CIF/CIF
- Video bit rate32 Kbps to 4 Mbps
- Video compressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Dual streamSupport
- Stream typeVideo, Video & Audio
- Audio compressionG.711u
- Audio bit rate64 Kbps
- Video and Audio
- Audio input1-ch, RCA (2.0 Vp-p, 1 KΩ)
- Audio output1-ch, RCA (Linear, 1 KΩ)
- Synchronous playback16-ch
- IP video input2-ch (up to 18-ch);Up to 5MP resolution;Support H.265+/H.265/H.264+/H.264 IP cameras
- HDTVI input1080p25, 1080p30, 720p25, 720p30
- HDCVI input1080p25, 1080p30, 720p25, 720p30
- CVBS inputPAL/NTSC
- Two-way audio1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
- Analog video input16-ch;BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- AHD input1080p25, 1080p30, 720p25, 720p30
- CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω),
resolution: PAL: 704 × 576, NTSC: 704 × 480
- HDMI/VGA output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- Network
- Network protocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
- Remote connections128
- Network interface1, RJ45 10M/100M self-adaptive Ethernet interface
- Auxiliary interface
- CapacityUp to 10 TB capacity for each disk
- Serial interfaceN/A
- USB interface
2× USB 2.0
- Alarm in/outN/A
- SATA1 SATA interface
- General
- Consumption(without HDD)≤ 10 W
- Working humidity10% to 90%
- Power supply12 VDC
- Working temperature-10 °C to +55 °C (+14 °F to +131 °F)
- Dimensions(W × D × H)260 × 222 × 45 mm (10.2 × 8.7 × 1.8 inch)
- Weights (without HDD)≤ 1.1 kg (2.4 lb)
