- Perimeter Protection
- Human/Vehicle AnalysisFalse alarm filtering for 4-ch behavior (line crossing and intrusion) detection for 2 MP, 3 MP, and 4 MP network camera
- Video and Audio
- IP Video Input16-ch
- HDMI Output4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,4K resolution is only available for HDMI.,
- VGA OutputHDMI,VGA
- CVBS Output1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
- Incoming Bandwidth256 Mbps/200 Mbps
- Audio Output1-ch, RCA (Linear, 1 KΩ)
- Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 k Ω)
- Decoding
- Decoding FormatH.265+,H.265,H.264+,H.264
- Decoding Capability12-ch@1080p
- Synchronous playback16-ch
- Recording Resolution12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/,DCIF/2CIF/CIF/QCIF,
- Network
- Network Interface1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
- PoE
- Interface16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
- Power≤ 200W
- StandardIEEE 802.3 af/at
- RAID
- RAID TypeNo
- Auxiliary Interface
- SATA4
- eSATA1 eSATA interface
- CapacityUp to 8 TB capacity for each HDD
- Serial InterfaceRS-485 (half-duplex), RS-232, Keyboard
- USB InterfaceFront panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
- Alarm In/Out16/4
- General
- Power Supply100 to 240 VAC,≤ 300 W
- Consumption≤ 30 W
- Working Temperature-10° C to +55° C (+14° F to +131° F)
- Working Humidity10 to 90 %
- Chassis1.5U chassis
- Dimension (W × D × H)445 × 400 ×71 mm ( 17.5″× 15.7″ × 2.8″)
- Weight≤ 5 kg (11 lb)
