- Recording
- Video compressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
- Encoding resolution
When 1080p lite mode is not enabled:
4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF
When 1080p Lite mode is enabled:
4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF
- Frame rate
Main stream:
When 1080p Lite mode not enabled:
For 4 MP stream access:
4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps
For 1080p stream access:
1080p/720p @15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
When 1080p Lite mode enabled:
4 MP lite/3 MP@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF@12fps; CIF@25fps (P)/30fps (N)
- Video bit rate32 Kbps to 6 Mbps
- Dual streamSupport
- Stream typeVideo, Video & Audio
- Audio compressionG.711u
- Audio bit rate64 Kbps
- Video and Audio
- IP video input2-ch (up to 6-ch) Up to 6 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras
- Analog video input4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
- AHD input4 MP, 1080p25, 1080p30, 720p25, 720p30
- HDCVI input1080p25, 1080p30, 720p25, 720p30
- CVBS inputPAL/NTSC
- Audio input1-ch, RCA (2.0 Vp-p, 1 KΩ)
- Audio output1-ch, RCA (Linear, 1 KΩ)
- Two-way audio1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
- Synchronous playback4-ch
- HDTVI input
4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
*: The 3 MP signal input is only available for channel 1 of DS-7204HQHI-K1/P, channel 1/2 of DS-7208HQHI-K2/P, and channel 1/2/3/4 of DS-7216HQHI-K2/P.
- VGA/HDMI output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- PoC camera inputSupport Hikvision PoC camera *: PoC access capability see Appendix.
- CVBS output1-ch, BNC (1.0 Vp-p, 75 Ω),resolution: PAL: 704 × 576, NTSC: 704 × 480
- Network
- Remote connections32
- Network protocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
- Network interface1, RJ45 10M/100M self-adaptive Ethernet interface
- Auxiliary interface
- SATA1 SATA interface
- CapacityUp to 10 TB capacity for each disk
- Alarm in/outN/A
- USB interface2 × USB 2.0
- Serial interfaceRS-485 (half-duplex)
- General
- Power supply48 VDC
- Working temperature-10 °C to +55 °C (+14 °F to +131 °F)
- Working humidity10% to 90%
- Dimensions (W × D × H)315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch)
- Weights (without HDD)≤ 1.16 kg (2.6 lb)
- Consumption (without HDD)≤ 40 W
