- Video and Audio
- IP Video Input8-ch
- HDMI Output1-ch, resolution: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
- VGA OutputHDMI,VGA
- Incoming Bandwidth50/40 Mbps
- Audio Output1-ch, RCA (linear, 1 KΩ)
- Decoding
- Decoding FormatH.265+,H.265,H.264+,H.264
- Decoding Capability4-ch@1080p
- Synchronous playback8-ch
- Recording Resolution4 M/3 M/1080p/1.3 M/720p
- Network
- Network Interface1, RJ45 10/100M Ethernet interface
- PoE
- InterfaceN/A
- Wireless Parameter
- Frequency Band2.4 GHz
- Antenna Structure2 × 2MIMO
- Transmission Speed144 Mbps
- Transmission StandardIEEE 802.11b/g/n
- RAID
- RAID TypeNo
- Auxiliary Interface
- SATA1 SATA interface
- CapacityUp to 6 TB capacity for each disk
- USB InterfaceRear panel: 2 × USB 2.0
- General
- Power Supply12 VDC
- Consumption≤ 12 W
- Working Temperature-10 °C to +55 °C (14 °F to 131 °F)
- Working Humidity10% to 90%
- Dimension (W × D × H)260 × 246 × 48 mm (10.2″ × 9.7″ × 1.9″)
- Weight≤ 1 kg (2.2 lb)
