- Network Parameters
- Port Number1 × 10/100 Mbps Hi-PoE port, 3 × 10/100 Mbps PoE ports, and 2 × 10/100 Mbps RJ45 ports
- Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive
- StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x
- Forwarding ModeStore-and-forward switching
- Working ModeStandard mode (default); Extend mode
- High priority portsPorts 1 to 2
- Ports for Long-Distance TransmissionPorts 1 to 4
- MAC Address Table2 K
- Switching Capacity1.2 Gbps
- Packet Forwarding Rate0.893 Mpps
- Internal Cache768 Kbits
- PoE Power Supply
- PoE Standard
Port 1: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Ports 2 to 4: IEEE 802.3af, IEEE 802.3at
- PoE Power PinSupport 8-core power supply, Ethernet cable 1/2/3/6 and 4/5/7/8 provide power supply simultaneously.
- PoE PortPorts 1 to 4
- Max. Port Power
Port 1: 60 W
Ports 2 to 4: 30 W
- PoE Power Pudget60 W
- Max. Power Consumption65 W
- General
- ShellMetal material, fan-free design
- Gross Weight0.77 kg (1.70 lb)
- Net Weight0.24 kg (0.53 lb)
- Dimension (L × H × D)145 mm × 25.6 mm × 68.45 mm (5.7” × 1.0” × 2.7”)
- Operating Temperature-10 °C to 55 °C (14 °F to 131 °F)
- Storage Temperature-40 °C to 85 °C (-40 °F to 185 °F)
- Operating Humidity5% to 95% (no condensation)
- Storage Humidity5% to 95% (no condensation)
- Power Supply48 VDC, 1.35 A
- Power Consumption in Idle5 W
- Approval
- EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016)
- SafetyUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
- ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
