- Thermal Module
- Image sensorVanadium Oxide Uncooled Focal Plane Arrays
- Pixel Interval17μm
- Response Waveband8μm to 14μm
- NETDless than 40 mk (0.04°C), F#=1.1
- MRAD5.48 mrad
- Field of View50° × 37.2° (H × V)
- Min. Focusing Distance0.2 m
- ApertureF1.1
- Optical Module
- Max. Resolution1920 × 1080
- Image Sensor1/2.8” Progressive Scan CMOS
- Min. IlluminationColor: 0.0025 Lux @(F1.6, AGC ON), B/W: 0.0012 Lux @(F1.6, AGC ON)
- Field of View87° × 46.2°(H × V)
- WDR120 dB
- Shutter Speed1s to 1/100,000s
- Day & NightIR cut filter with auto switch
- Image Function
- Bi-spectrum Image FusionFusion view of thermal view and overlaid details of the optical channel
- Picture in PictureCombines details of thermal and optical image PIP, overlay thermal image on optical image
- Smart Function
- VCA(Video Content Analysis)4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 8 VCA rules.
- Temperature Measurement3 temperature measurement rule types, 21 rules (10 points, 10 regions, and 1 line).
- Temperature Range-20 °C to 150 °C (-4 °F to 302 °F)
- Temperature Accuracy±8 °C (14.4 °F)
- Fire DetectionDynamic fire point detection, up to 10 fire points detectable.
- Infrared
- IR DistanceUp to 40 m
- IR Intensity and AngleAutomatically adjusted
- Network
- Main StreamVisible Light: 50Hz: 25fps (1920 × 1080), 25fps (1280 × 960), 25fps (1280 × 720),Visible Light: 60Hz: 30fps (1920 × 1080), 30fps (1280 × 960), 30fps (1280 × 720),Thermal: 25fps (160 × 120 (the resolution of output image is 320 × 240))
- Sub streamVisible Light: 50Hz: 25fps (704 × 576), 25fps (352 × 288), 25fps (176 × 144),Visible Light: 60Hz: 30fps (704 × 480), 30fps (352 × 240), 30fps (176 × 120),Thermal: 25fps (160 × 120 (the resolution of output image is 320 × 240))
- Video compressionH.265/H.264/MJPEG, H.265+/H.264+ encoding with Baseline/Main/High Profile
- Audio compressionG.711u/G.711a/G.722.1/MP2L2/G.726/PCM
- ProtocolsIPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS,NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
- Simultaneous live viewUp to 20
- User/Host levelUp to 32 users, 3 levels: Administrator, Operator, User
- Security measuresUser authentication (ID and PW), MAC address binding, HTTPS encryption, IEEE 802.1x access control, IP address filtering
- Integration
- Alarm Input2-ch inputs (0-5V DC)
- Alarm Output2-ch relay outputs, alarm response actions configurable
- Alarm ActionPreset/Patrol Scan/ Pattern Scan/SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage
- Audio Input1 3.5mm Mic in/Line in interface. Line input: 2-2.4V[p-p], output impedance:1KΩ±10%
- Audio OutputLinear Level; Impedance: 600Ω
- Reset1 Reset Button
- Ethernet1 RJ45 10M/100M Self-adaptive Ethernet interface
- SD Memory CardBuilt-in Micro SD card slot, support Micro SD/SDHC/SDXC card (up to 256 G), support manual/alarm recording
- Analog Video Output1.0V [p-p]/75Ω, PAL/NTSC/BNC
- Application ProgrammingOpen-ended API, support ISAPI, HIKVISION SDK and third-party management platform
- ClientiVMS-4200
- Web BrowserIE8-IE11, chrome41-chrome44, Firefox 30-Firefox51
- General
- Menu LanguageEnglish
- Power12 VDC± 20%,PoE (802.3at, class 4)
- Power Consumption12 VDC± 20%: max. 12W,PoE (802.3at, class 4)
- Work Temperature/Humidity-40 °C to 60 °C (-40 °F to 140 °F), 90% or less
- Protection LevelIP66 Standard,TVS 6000V Lightning protection, surge protection, voltage transient protection
- Dimensions352.4 mm × 113.5 mm × 114.7 mm (13.9 ” × 4.5″ × 4.5 “)
- WeightApprox. 1.5Kg (3.3lb)
