- Camera
- Image Sensor2 MP CMOS image sensor
- Max. Resolution1920 (H) × 1080 (V)
- Min. Illumination0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
- Shutter Time1/25 (1/30) s to 1/50,000 s
- Day & NightIR cut filter
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
- Signal SystemPAL/NTSC
- Lens
- Lens Type3.6 mm 2.8 mm, 6 mm fixed lens
- Focal Length & FOV103° (2.8 mm), 82.2° (3.6 mm), 54° (6 mm)
- Lens MountM12
- Image
- Image SettingsBrightness, Sharpness, DNR, Mirror
- Frame RatePAL: 1080p@25fps,NTSC: 1080p@30fps
- Day/Night ModeSmart/color/BW(Black and White)
- Wide Dynamic Range (WDR)DWDR
- Image EnhancementBLC
- AGCLow/middle/high
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- General
- MaterialPlastic
- DimensionΦ 110 mm × 93.2 mm (4.33″ × 3.67″)
- WeightApprox. 350 g (0.77 lb.)
- Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)
- LanguageEnglish, Chinese
- Power Supply12 VDC±15%
- ConsumptionMax. 4 W
- IR RangeUp to 20 m
- Approval
- ProtectionIP66
