- Camera
- Image Sensor5 megapixel progressive scan CMOS
- Max. Resolution2560 (H) × 1944 (V)
- Min. IlluminationColor: 0.003 Lux@(F1.2, AGC ON), 0 Lux with IR
- Shutter TimePAL: 1/25 s to 1/50,000 s,NTSC: 1/30 s to 1/50,000 s
- Day & NightIR cut filter
- Angle AdjustmentPan: 0° to 360°, Tilt:0° to 180°, Rotate: 0° to 360°
- Signal SystemPAL/NTSC
- Lens
- Lens Type2.8 mm, 3.6 mm, 6 mm fixed lens
- Focal Length & FOV98° (2.8 mm), 78° (3.6 mm), 48° (6 mm)
- Lens MountM12
- Image
- Image SettingsBrightness, Sharpness, 3D DNR, Mirror, Smart IR
- Frame RateTVI: 2 MP@25fps, 2 MP@30fps, 4 MP@25fps, 4 MP@30fps, 5 MP@20fps,AHD: 4 MP@25fps, 4 MP@30fps, 5 MP@20fps,CVI: 4 MP@25fps, 4 MP@30fps,CVBS: PAL, NTSC
- Day/Night ModeAuto/Color/BW (Black and White)
- Wide Dynamic Range (WDR)≥ 130 dB
- Image EnhancementBLC
- Privacy Mask4 programmable privacy masks
- Noise ReductionLevel 1 to 9
- White BalanceAuto/Manual
- AGCYes
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- Event
- Motion Detection4 programmable areas
- General
- MaterialMetal
- Dimension58 mm × 61 mm × 158.6 mm (2.28″ × 2.40″ × 6.42″)
- WeightApprox. 320 g (0.71 lb.)
- Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensing)
- CommunicationUp the coax, Protocol: HIKVISION-C (TVI output)
- LanguageEnglish
- Power Supply12 VDC ±25%,*You are recommended to use one power adapter to supply the power for one camera.
- ConsumptionMax. 5.8 W
- IR RangeUp to 30 m
- Approval
- ProtectionIP67
