Camera
Strobe Light Alarm: Yes
Slow Shutter: Max. 16 times
WDR (Wide Dynamic Range): ≥130 dB
Angle Adjustment: Pan: 0°to 360°, Tilt: 0°to 180°, Rotate: 0°to 360°
Image Sensor: 2MP CMOS Image Sensor
Signal System: PAL/NTSC
Min. Illumination: Color: 0.003 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Time: PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s
Lens: 2.8 mm, 3.6 mm fixed focal lens
Lens Mount: M12
Day& Night: IR cut filter
Horizontal Resolution: 1920 (H) × 1080 (V)
Video Frame Rate: PAL: 1080p@25fps
NTSC: 1080p@30fps
Synchronization: Internal Synchronization
Lens
Horizontal Field of View: 2.8 mm, horizontal FOV: 103.5°, vertical FOV: 55°, diagonal FOV: 119°
3.6 mm, horizontal FOV: 79.1°, vertical FOV: 43°, diagonal FOV: 92°
Menu
Image Mode: STD/HIGH-SAT
Noise Reduction: 3D DNR/2D DNR
Automatic Exposure: WDR/BLC/HLC/Global
White Light: AUTO/OFF
D/N Mode: Auto/Color/BW (Black and White)
Auto White Balance: Auto / Manual
Private Mask: ON/OFF, 4 programmable privacy masks
Motion Detection: 4 programmable motion areas
AGC: Yes
Language: English
Function: Brightness, Sharpness, Mirror, Smart IR
White Balance: Auto/Manual
Interface
Video Out: 1 HD analog output
General
White Light: Up to 20 m
PIR Range: Angle: 110°, Range:11 m
Material: Metal
Ingress Protection: IP67
Operating Conditions: -40 °C – 60 °C (-40 °F – 140 °F)
Humidity 90% or less (non-condensing)
Power Supply: 12 VDC ±25% *You are recommended to use one power adapter to supply the power for one camera.
Power Consumption: Max. 3.9 W
Weather Proof: IP67
IR Range: Up to 20m
Communication : HIKVISION-C
Dimension: 68 mm × 70 mm × 179.8 mm (2.68″ × 2.76″ × 7.08″)
Weight: Approx. 358 g (0.79 lb.)
