- Camera
- Image Sensor1/2.8″ Progressive Scan CMOS
- Min. Illumination0.009 Lux @ (F1.6, AGC ON), 0 Lux with IR
- Shutter Speed1/3 s to 1/100,000 s
- Slow ShutterYes
- Wide Dynamic Range120dB
- Day & NightIR cut filter
- Angle AdjustmentPan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
- Lens
- FocusFixed
- Lens Type2.8/4/6/8 mm
- FOV2.8 mm, horizontal field of view: 108°, vertical FOV: 58°, diagonal FOV: 128° ;4 mm, horizontal field of view: 86°, vertical FOV: 46°, diagonal FOV: 103° ;6 mm, horizontal field of view: 52°, vertical FOV: 29°, diagonal FOV: 60° ;8 mm, horizontal field of view: 41°, vertical FOV: 22°, diagonal FOV: 47°
- ApertureF1.6
- Lens MountM12
- Aperture TypeFixed
- Illuminator
- IR RangeUp to 80 m
- Wavelength850 nm
- Video
- Max. Resolution1920 × 1080
- Main Stream50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) ;60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
- Sub Stream50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) ;60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
- Video Compression Main stream: H.265/H.264 ;Sub-stream: H.265/H.264/MJPEG ;Third stream:H.265/H.264
- Video Bit Rate32 Kbps to 16 Mbps
- H.264 TypeMain Profile/High Profile
- H.265 TypeMain Profile
- H.264+Main stream supports
- H.265+Main stream supports
- Scalable Video Coding (SVC)H.265 encoding and H.264 encoding support
- Region of Interest (ROI)Support 4 fixed region for main stream and sub-stream separately
- Network
- Simultaneous Live ViewUp to 6 channels
- APIONVIF (PROFILE S, PROFILE G), ISAPI
- ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
- User/HostUp to 32 users,3 levels: Administrator, Operator and User
- Network StorageSupport microSD/SDHC/SDXC card (128G) local storage, NAS (NFS,SMB/CIFS), ANR
- ClientiVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
- Web BrowserIE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11
- Alarm TriggerMotion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error
- Image
- Day/Night SwitchDay/Night/Auto/Schedule
- DNR3D DNR
- Image EnhancementBLC/3D DNR/HLC
- Image SettingsSaturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
- Interface
- On-board StorageBuilt-in micro SD/SDHC/SDXC slot, up to 128 GB
- Hardware ResetYes
- Communication Interface1 RJ45 10M/100M self-adaptive Ethernet port
- Event
- Smart EventLine crossing detection, intrusion detection, region entrance detection, region exit detection, false alarm filter by target classification
- General
- Firmware VersionV5.5.72
- General FunctionOne-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
- Startup and Operating Conditions-30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing)
- Power Supply12 VDC ± 25%, 5.5 mm coaxial power plug,PoE (802.3at, class 4)
- Power Consumption and Current12 VDC, 1.25 A, max. 15 W,PoE: (802.3at, 42.5 V to 57 V), 0.42 A to 0.32 A, max. 18 W
- Camera DimensionCamera: Φ 105 × 292.2 mm (Φ 4.1″ × 11.5″) ;With package: 385 × 190 × 180 mm (15.2″ × 7.5″ × 7.1″)
- Camera WeightCamera: 1320 g (2.9 lb.) ;With package: 1924 g (4.2 lb.)
- Approval
- ProtectionIP66
