- Camera
- Image Sensor1/2.8″ Progressive Scan CMOS
- Min. IlluminationColor: 0.01 Lux @ (F1.2, AGC ON), 0.028Lux @(F2.0, AGC ON); B/W: 0.001 Lux @(F1.2, AGC ON), 0.0028 Lux @(F2.0, AGC ON)
- Shutter Speed1/3 s to 1/100,000 s
- Slow ShutterYes
- Wide Dynamic Range120dB
- Day & NightIR Cut Filter
- Lens
- FocusFixed
- Lens Type4/6 mm
- FOV4 mm: horizontal FOV: 86°, vertical FOV: 47°, diagonal FOV: 103°;6 mm: horizontal FOV: 55°, vertical FOV: 31°, diagonal FOV: 62°
- ApertureF2.0
- Lens MountM12
- Aperture TypeFixed
- Illuminator
- IR Range30 m
- Wavelength850nm
- Video
- Max. Resolution1920 × 1080
- Main Stream50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720);60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
- Sub Stream50Hz: 25fps (704 × 576, 640 × 480, 352 × 288, 320 × 240);60Hz: 30fps (704 × 480, 640 × 480, 352 × 240, 320 × 240)
- Video Compression Main stream: H.265/H.264;Sub-stream: H.265/H.264/MJPEG
- Video Bit Rate32 Kbps to 8 Mbps
- H.264 TypeBaseline Profile/Main Profile/High Profile
- H.265 TypeMain Profile
- H.264+Main stream supports
- H.265+Main stream supports
- Region of Interest (ROI)1 fixed region for main stream
- Audio
- Environment Noise FilteringYes
- Audio Sampling Rate8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
- Audio Compression G.711/G.722.1/G.726/MP2L2/PCM
- Audio Bit Rate64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
- Network
- Simultaneous Live ViewUp to 6 channels
- APIONVIF (PROFILE S, PROFILE G), ISAPI
- ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
- User/HostUp to 32 users,3 levels: Administrator, Operator and User
- Network StorageSupport Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
- ClientiVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
- Web BrowserIE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
- Alarm TriggerMotion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error
- Image
- Day/Night SwitchDay/Night/Auto/Schedule/Triggered by alarm in
- Target CroppingNo
- DNR3D DNR
- Image EnhancementBLC/3D DNR
- Image SettingsRotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser
- Interface
- Audio1 input (line in), 1 output (line out), mono sound
- Alarm 1 input, 1 output
- On-board StorageBuilt-in Micro SD/SDHC/SDXC slot, up to 128 GB
- Hardware ResetYes
- Communication Interface1 RJ45 10M/100M self-adaptive Ethernet port
- Event
- Smart EventLine crossing detection, intrusion detection
- General
- Firmware VersionV5.5.3
- General FunctionAnti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
- Startup and Operating Conditions-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
- Power Supply12 VDC ± 25% , PoE (802.3af, class 3)
- Power Consumption and CurrentPoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max: 6.5 W, 12 VDC, 0.4 A, max. 5.0 W
- Camera DimensionCamera: 93.9 × 93.5 × 194.1 mm (3.7″ × 3.7″ × 7.6″);With package: 300 × 205 × 135 mm (11.8″ × 8.1″ × 5.3″)
- Camera WeightCamera: approx. 680 g (1.5 lb.)With package: approx. 1000 g (2.2 lb.)
- Approval
- ProtectionIP67
