- General
- Core Color1 White- Blue /Blue 2 White-Orange /Orange,3 White- Green /Green 4 White- Brown /Brown,
- PackingWooden Tray & Carton
- Carton DimensionPer request
- Packing length305±1.5m/80±0.5m
- Rip-cordYes
- Drain wireNo
- Sheath Physical PropertiesBefore Aging Tensile Strength (Mpa) ≥13.5, Elongation(%) ≥150,Aging Period(℃×hrs) 100℃×24h×7d,After Aging Tensile Strength(Mpa) ≥12.5, Elongation(%) ≥125,Cold bend(-20±2℃×4h) 8×Cable O.D.，No visible cracks,
- Electrical Characteristics (20℃)1.0-100.0MHz Impedance(Ω) 100±15,1.0-100.0MHz Delay Shew (ns/100m) ≤45,DC Resistance Ω/100m) max 14.8,DC Conductor Resistance Unbalance(%) max 5.0,
- Conductor
- MaterialSolid-Bare Copper,Content 99.95%,
- Nom.O.D.(mm)0.450±0.005
- Insulation
- MaterialHDPE
- Diameter0.82±0.04mm
- Sheath
- Thickness0.50±0.05 mm
- External O.D.4.7±0.4 mm
- SurfaceClean,Frap,Satiation
- MaterialPVC(complies RoHS),CMX
- ColorGrey ZLC1003
- Surface Printing
- Letter height3.0±0.3mm
- ColorBlack
- Print error & Space≤±0.5%，1m
