Features:
• Starlight, 120dB true WDR, 3DNR
• Max 30fps@1080P
• HD and SD output switchable
• 2.8mm fixed lens (3.6mm, 6mm optional)
• Max. IR length 20m, Smart IR
• IP67, IK10, DC12V
Technical Specifications:
Camera
• Image Sensor 1/2.8″ CMOS
• Effective Pixels 1937(H)Ч1097(V), 2.1MP
• Scanning System Progressive
• Electronic Shutter Speed PAL: 1/4s~1/100000s NTSC: 1/3s~1/100000s
• Minimum Illumination 0.005Lux/F1.6, 30IRE, 0Lux IR on
• S/N Ratio More than 65dB
• IR Distance Up to 20m (66feet)
• IR On/Off Control Auto / Manual
• IR LEDs 8
Lens
• Lens Type Fixed lens / Fixed iris
• Mount Type Board-in
• Focal Length 2.8mm (3.6mm, 6mm Optional)
• Max Aperture F1.6
• Angle of View H: 110.5° (87°/52.9°)
• Focus Control N/A
• Close Focus Distance 1200mm (500mm, 1800mm)
Pan / Tilt / Rotation
• Pan: 0° ~ 60°
• Tilt: 0° ~ 80°
• Rotation: 0° ~ 360°
Video
• Resolution 1080P (1920Ч1080)
• Frame Rate 25/30fps@1080P, 25/30fps@720P
• Video Output 1-channel BNC high definition video output / CVBS video output (Can switch)
• Day/Night Auto (ICR) / Manual
• OSD Menu Multi-language
• BLC Mode BLC / HLC / WDR
• WDR 120dB
• Gain Control AGC
• Noise Reduction 2D / 3D
• White Balance Auto / Manual
• Smart IR Auto / Manual
Certifications
• CE (EN55032, EN55024, EN50130-4)
• FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
• UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Interface
• Audio Interface N/A
Eelectrical
• Power Supply 12V DC ±25%
• Power Consumption Max 2.4W (12V DC, IR on)
Environmental
• Operating Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH
• Start up should be done at above -40°C (-40°F)
• Storage Conditions -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH
Ingress Protection & Vandal
• Resistance IP67 & IK10
Construction
• Casing Aluminium
• Dimensions F106mmЧ50.3mm (F4.17″Ч1.98″)
• Net Weight 0.31kg (0.68lb)
• Gross Weight 0.45kg (0.99lb)
