Specifications
Camera:
- Image sensor: 1 / 2.8 “2.1 Megapixel CMOS
- Number of pixels: 1937×1097
- Minimum illumination: 0.005Lux / F1.6, 30IRE, 0Lux IR on
- IR distance: up to 30m, Smart IR
- IR on / off: auto / manual
- IR LEDs: 12
Lens:
- Lens type: fixed lens / fixed iris
- Focal length: 3.6mm
- Maximum opening: F1.6
- Horizontal opening angle: 87 °
- Focus control: none
Position camera:
- Pan / Tilt / Rotation:
- Pan: 0 ~ 355 °
- Tilt: 0 ~ 65 °
- Rotation: 0 ~ 355 °
Video:
- Resolution: 2MP (1920×1080)
- Frame rate: 25fps 1080p, 25fps 720p
- Video output: 1 channel BNC HD-CVI / BNC CVBS to switch with the PFM820
- Day / night: car (ICR) / manual
- On Screen display (OSD): supported
- BLC mode: BLC / HLC / WDR (120dB)
- Gain control: AGC
- Noise reduction: 2D / 3D
- White balance: auto / manual
- Smart IR: auto / manual
Audio:
- Interface: none
Electric:
- Power supply: 12VDC +/- 25%
- Consumption: max. 3.5W, (12VDC, IR on)
Surroundings:
- Working temperature: -40 to 60 degrees
- Water resistance: IP67
- Vandal resistance: IK10
Construction:
- Material: aluminum
- Dimensions: Ø109.9x81mm
