System
- Main Processor: Dual-core embedded processor
- Operating System: Embedded LINUX
Audio and Video
- IP Camera Input: 8 Channel
- Two-way Talk: 1 Channel Input, 1 Channel Output, RCA
Display
- Interface: 1 HDMI, 1 VGA
- Resolution: HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 / VGA: 1920×1080, 1280×1024, 1280×720
- Decoding Capacity: 1ch@8MP 30fps, 4ch@1080P 30fps
- Multi-screen Display: 1/4/8/9
- OSD: Camera title, Time, Camera lock, Motion detection, Recording
Recording
- Compression: H.265/H.264
- Resolution: 8MP/6MP/5MP/4MP/3MP/1080P/ 720P/ D1&etc.
- Record Rate: 80Mbps
- Bit Rate: 16Kbps ~ 20Mbps Per Channel
- Record Mode: Manual, Schedule(Regular(Continuous), MD, Stop
- Record Interval: 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection and Alarm
- Trigger Events: Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips
- Video Detection: Motion Detection, MD Zones: 396 (22 × 18), and Tampering
Playback and Backup
- Sync Playback: 1/4
- Search Mode: Time /Date, MD and Exact Search (accurate to second)
- Playback Function: Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Shuffle, Backup Selection, Digital Zoom
- Backup Mode: USB Device/Network
Third-party Support
- Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more
Network
- Interface: 1 RJ-45 port (10/100Mbps)
- Network Function: HTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, DDNS, IP Search(Support Dahua IP camera, DVR, NVS and etc.), Easy4ip
- Max. User Access: 128 users
- Smart Phone: iPhone, iPad, Android
- Interoperability: ONVIF 2.4, SDK, CGI
Storage
- Internal HDD: 1 SATA III Port, up to 6TB capacity for each HDD
- HDD Mode: Single
Auxiliary Interface
- USB: 2 ports (1 Rear USB2.0, 1 Front USB2.0)
Electrical
- Power Supply: Single, DC12V/2A
- Power Consumption: <3W (without HDD)
Environmental
- Operating Conditions: -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa
- Storage Conditions: -20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH
Construction
- Dimensions(W×D×H): Compact 1U, 260mm×224.9mm×47.6mm
- Net Weight: 0.8kg (1.76 lb) (without HDD)
- Gross Weight: 1.6kg(3.53 lb)(without HDD)
Certifications
CE: EN55032, EN55024, EN50130-4, EN60950-1
FCC: Part 15 Subpart B, ANSI C63.4-2014
UL: UL60950-1
