Camera
Image Sensor 1/2.8” 2Megapixel progressive scan CMOS
Effective Pixels 1920(H) x 1080(V)
RAM/ROM 256MB/32MB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual, 1/3(4)~1/100000s
Minimum Illumination
0.009Lux/F2.0( Color,1/3s,30IRE)
0.07Lux/2.0( Color,1/30s,30IRE)
0Lux/F2.0(IR on)
S/N Ratio More than 50dB
IR Distance Distance up to 50m (164ft)
IR On/Off Control Auto/ Manual
IR LEDs 1
Lens
Lens Type Fixed
Mount Type Board-in
Focal Length 3.6mm (6mm optional)
Max. Aperture F2.0 (F2.0)
Angle of View H: 87° (51°), V: 48°(30°)
Optical Zoom N/A
Focus Control Fixed
Close Focus Distance N/A
Construction
Casing Metal
Dimensions 241.8mm×90.4mm×90.3mm (9.52”×3.56”×3.56”)
Net Weight 0.61Kg (1.35lb)
Gross Weight 0.8kg (1.77lb)
