Features

Green features

• IEEE802.3az EEE (Energy Efficient Ethernet)
• RoHS compliant

Standards

• IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
• IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
• IEEE 802.3az Energy-Efficient Ethernet (EEE)
• ANSI/IEEE 802.3 NWay auto-negotiation

Versatile Support

• Plug-and-play installation
• Full/half-duplex for Ethernet/Fast Ethernet speeds
• IEEE 802.3x Flow Control

Technical Specifications

General

Standards

• IEEE 802.3 10BASE-T Ethernet (twisted pair copper)
• IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
• ANSI/IEEE 802.3 NWay auto-negotiation
• IEEE 802.3x flow control
• IEEE 802.3az EEE function

LAN

• IEEE 802.3 10BASE-T
• IEEE 802.3u 100BASE-TX compliance
• IEEE 802.3x Flow Control support

Data Transfer Rates

• Fast Ethernet
  • 100 Mbps Half-Duplex
  • 200 Mbps Full-Duplex
• Ethernet
  • 10 Mbps Half-Duplex
  • 20 Mbps Full-Duplex

Functionality

Port Packet Filtering/Forwarding Rate

• 148,800 pps for 100 M
• 14,880 pps for 10 M

Swithing Fabric

• 3.2 Gbps switching fabric

Number of Ports

• 16 10/100Mbps Fast Ethernet ports

Network Cables

• 10BASE-T:
  • UTP CAT 3/4/5/5e (100 m max.)
  • EIA/TIA-586 100-ohm STP (100 m max.)
• 100BASE-TX
  • UTP CAT 5/5e (100 m max.)
  • EIA/TIA-568 100-ohm STP (100 m max.)

Media Interface Exchange

Auto MDI/MDIX adjustment for all ports

LED Indicators

• Per port:
  • Link/Activity
• Per device:
  • Power

Transmission Method

•  Store-and-forward

MAC Address Table

• 8K entries per device

MAC Address Learning

• Automatic update

Packet Filtering /Forwarding Rates

• Ethernet: 14,880 pps per port
• Fast Ethernet: 148,800 pps per port

Topology

• Star

Protocol

• CSMA/CD

Physical

Dimensions

• 282 x 150 x 44 mm (11.1 x 5.91 x 1.73 inches)

Weight

• 1.06 kg (2.34 lbs)

Power Consumption

• Standard Power Consumption: 0.9 Watts
• Maximum Power Consumption: 2.1 Watts

ion

• 7.1652 BTU/h

MTBF

• 492,096 hours

Temperature

• Operating: 0 to 40 °C (32 to 104 °F)
• Storage: -10 to 70 °C (14 to 158 °F)

Humidity

• Operating: 10% to 90% non-condensing
• Storage: 5% to 90% non-condensing

Certifications

• CE
• FCC
• ICES-003
• BSMI
• RCM
• CCC
• VCCI
• cUL
• CB
• LVD
